Kitchen Organization
Corner Solutions

Lazy Susans
3
> Tested to 100,000 cycles
> Made in USA
> Telescopic post adjusts without tools
> Anti-slip ribs for sliding resistance
> Shelves are safely secured with a steel pin through the post
> Rigid double wall tray construction guarantees a heavy weight
carrying capacity
> Top and bottom shelf height adjustment
> Single bump stop
> Inside shelf rim height: 28 mm (1 1/8")
> Weight capacity per shelf: 457 mm (18") - 12.7 kg (28 lbs.) Kitchen Organization
610 mm (24") - 22.6 kg (50 lbs.)
710 mm (28") - 31.7 kg (70 lbs.)
> Door height adjustment (± 5 mm) without tools
> For revolving door applications
> Post fits inside cabinet heights: 660–813 mm (26"–32")
> Material: Polypropylene; Color: white; Post: Steel; Finish: chrome

→ Pie-Cut Lazy Susan

Ø Item No.
457 (18") 542.94.751
610 (24") 542.94.752
711 (28") 542.94.754
Supplied With
2 Shelves
Post
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Shelves attached to revolving door J
C H
A I
B E F
J D G
H C D
A B C E F G H I J
(max.)
I 838 209 610 44 457 230 35 265 230 49 279
(33") (9") (24") (1 3/4") (18") (9 1/16") (1 3/8") (10 7/16") (9 1/16") (1 15/16") (11")
914 305 610 44 610 300 40 341 300 59 359
(36") (12") (24") (1 3/4") (24") (11 13/16") (1 5/8") (13 7/16") (11 13/16") (2 5/16") (14 1/8")
B 914 305 610 44 711 351 91 442 351 128 480
(36") (12") (24") (1 3/4") (28") (13 13/16") (3 9/16") (17 3/8") (13 13/16") (5 1/16") (18 7/8")
D
E F
G
