Casters, Feet, Legs, Table Fittings
Base Cabinet Feet

Mounting Plates and Clips

Mounting with the plinth Mounting with the plinth > Base heights listed are total including mounting plate, tube,
panel spring - front plinth panel clip
and adjusting foot
> Bayonet locking of the tube in the mounting plate prevents the
tube from pulling out during tilting, especially on tall cabinets
min. 3 (1/8") > Plinth panel attaches with the clips shown, or with Velcro applied
max. 18 (11/16")
to the mounting plate recess
16 / 13
(5/8" / 1/2")

→ Square Mounting Plate
10 (3/8")
11 > For Ø78 mm (3 1/16") foot
(7/16") > Material: Plastic; Color: black

Mounting Item No.
25 (1") Press-fit 637.79.300
Screw mounted 637.79.301
6 Mounting Supplied With 4 Plates
plate
Recess for
velcro tabs
(not supplied) Tube → Adjustment Foot/Tube
Ø35 and
(1 3/8") adjusting
Casters, Feet, Legs, Table Fittings

44 foot > For Ø78 mm (3 1/16") round mounting plate
(1 3/4") > Easily adjusts weights up to 150 kg (330 lbs.) per leg
> Heights listed are total, including mounting plate
> Adjustment range = -10/+18 mm
> Material: Plastic; Color: black
64
21 (2 1/2")
(13/16") Ø78
(3 1/16") Base height Item No.
80 (3 1/8") 637.80.350
64
(2 1/2") 100 (4") 637.80.351
120 (4 3/4") 637.80.352
7 (1/4") 150 (6") 637.80.353
Supplied With 4 Feet, 4 Tubes, Pre-mounted nails
→ Plinth Panel Clip → Plinth Panel Clip

52 52
(2 1/16") (2 1/16")
3.2
(1/8")

> For rectangular glide > Groove mounted; for rectangular glide
> Material: Plastic > Material: Plastic Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Color Item No. Color Item No.
black 637.81.588 black 637.81.590
Supplied With 4 Panel holders, Pre-mounted nails Supplied With 4 Panel holders

→ Plinth Panel Spring

> For front plinth mounting
> Plinth panel is removable with disassembly ring
> Material: Stainless Steel

Item No.
637.81.330
Supplied With 20 pcs.
FC 6.28 www.hafele.com/us
