Home and Closet Organization
Closet Brackets

Brackets and H-Channel

→ Angle Bracket
27 12
(1 1/16") (1/2") > Material: Steel, epoxy-coated
Flat Head
7.8 #6
4 (5/16") 27 Finish Item No.
(1 1/16") white 260.35.740
brown 260.35.140
7.8
(5/16") (1/8")
Home and Closet Organization 25.4 25.4 (1/16") (7/32") 13 Flat Head Note Item No.
2.3

→ Angle Bracket

> Fits inside the 260.24.XXX brackets to provide additional support
(1/2")
when attaching partitions to the wall
#6
> Material: Steel
5.9
(1")
1.8
260.35.990
(1")

→ Angle Bracket

19 Requires 2 wood screws.
(3/4") > With attached cover cap
Flat Head > Material: Plastic
#8
Ø4.5 34 Color Item No.
(3/16") (1 5/16") white 260.24.740
almond 260.24.440
brown 260.24.140
34
(1 5/16") black 260.24.340
gray 260.24.541
bronze 260.24.141
ivory 260.24.741
→ H-Channel

> Used to attach two shelves together side by side in a corner
application
> For use on 19 mm (3/4") material
> L x W x H: 327 x 22 x 25 mm (12 7/8" x 7/8" x 1")
> Material: Plastic Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Pan Head Color Item No.
white 282.79.700
almond 282.79.400
black 282.79.300
brown 282.79.110
gray 282.79.501
bronze 282.79.101
ivory 282.79.701

Flat head screws pages 12.7–12.8, 12.10, 12.13
Pan head screws pages 12.9–12.10
FC 4.156 www.hafele.com/us
