Home and Closet Organization
Accessories

Outlet Grommet and Label Frames

→ Outlet Grommet

90 18 > Creates a finished look where partitions must be cut to allow
(3 9/16") (23/32")
access to a light switch or wall socket
> Material: Plastic
163 143 4
(6 7/16") (5 5/8")
Color Single Double
white 631.24.760 631.24.761
111 almond 631.24.460 631.24.461
(4 3/8") 20
(13/16") brown 631.24.170 631.24.171
black 631.24.360 631.24.361
gray 631.24.560 631.24.561
162 20
(6 3/8") (13/16") bronze 631.24.160 631.24.161

140 ivory 631.24.470 631.24.471
162 (5 1/2")
(6 3/8")
140
(5 1/2")
Home and Closet Organization
19
(3/4")

→ Label Frame

A

Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
B

> Material: Steel; Finish: nickel-plated

A B Label Window Item No.
93 (3 11/16") 41 (1 5/8") 79 x 31 (3 1/8" x 1 1/4") 72 x 25 (2 13/16" x 1") 168.02.770
100 (3 15/16") 58 (2 5/16") 81 x 46 (3 3/16" x 1 13/16") 75 x 38 (2 15/16" x 1 1/2") 168.02.789
69 (2 11/16") 35 (1 3/8") 57 x 28 (2 1/4" x 1 1/8") 52 x 22 (2 1/16" x 7/8") 168.02.761

→ Label Frame

59 > Label: 52 x 14 mm (2 13/16" x 9/16")
> Window: 47 x 10 mm (1 7/8" x 3/8")
> Material: Steel
20
Finish Item No.
nickel-plated 168.00.713
