Home and Closet Organization
Wardrobe Fittings

Brackets

> Heavy duty steel
> Horizontal member adjusts 19 mm (3/4") for optional
19 mm (3/4") cleat
> Material: Steel, plated or epoxy-coated

→ Wardrobe Bracket → Wardrobe Bracket 4

Bracket Top Bracket Top

64 64
(2 1/2") 247.5 (2 1/2")
(9 3/4")
247.5
12.5 (9 3/4")
Ø5 (1/2") Ø5
25.5 25.5
(1") (1")
25 12.5
(1") (1/2") Home and Closet Organization

25.5
(1")
285
(11 1/4")
267
(10 1/2")
267 22
(10 1/2") (7/8") 56.8
310 (2 1/4")
(12 3/16")
44.3
(1 3/4") Ø15.5
31 (1 1/4") (5/8")
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Ø40.5
(1 5/8")

Pan Head Pan Head
#10 #10

Arm slides
Arm slides back and forth
back and forth

(shown in the
forward position)

> For round tube Ø40 mm (1 9/16") > For oval tube Ø15 mm (9/16")

Finish Item No. Finish Item No.
chrome 805.39.202 chrome 805.39.201
white epoxy 805.39.702 white epoxy 805.39.701

Pan head screws pages 12.9–12.10
