Home and Closet Organization
Wardrobe Fittings

TAG ENGAGE

> Easily reconfigured to meet your storage needs
> Jewelry trays and dividers customize the pull-out shelf
> Fabric lined bottom is standard
When used as a jewelry organizer, see next page
> The perfect jewelry storage solution that tucks under a fixed shelf
4 using minimal space
> A completely customizable grid specifically sized for jewelry, ties,
glasses and more
> Any combination of grid dividers can be removed, changing the
spacing so that it is perfectly sized for sunglasses, belts, larger
jewelry, mobile phones, etc.
Home and Closet Organization few or as many as desired
When used as a divided shelf, see next page
> Created specifically for jeans, shoes, handbags, hats and shirts
> Can be customized using 76 mm (3") tall shelf dividers, with as

> Color coordinated dividers can be set at any position
When used as a folding station:
> A clutter free space to fold clothing before storing
> Tucks neatly under a fixed shelf
> Simply remove the bottom, add a 19 mm (3/4") thick piece of
material and then reinstall the bottom to create a flush mounted
folding station

Bottom should be cut to the following dimensions when used as a
folding station
Shelf width
457 mm (18") Length Depth
376 mm (14 13/16")
306 mm (12 1/16")
610 mm (24") 529 mm (20 13/16") 306 mm (12 1/16")
762 mm (30") 681 mm (26 13/16") 306 mm (12 1/16")
→ Pull-Out Shelf

> H x D: 71 x 353 mm (2 13/16" x 13 7/8")
> Material: Frame: Aluminum; Bottom: Fabric

Width matt nickel; black; matt gold; slate; matt aluminum;
slate fabric beach fabric beach fabric slate fabric slate fabric
457 (18") 807.77.601 807.78.301 807.77.901 807.78.101 807.77.001
610 (24") 807.77.602 807.78.302 807.77.902 807.78.102 807.77.002
762 (30") 807.77.603 807.78.303 807.77.903 807.78.103 807.77.003
915 (36") 807.77.604 807.78.304 807.77.904 807.78.104 807.77.004
Supplied With
Full extension, soft close undermount slides

→ Drawer Face Adapter, optional Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

> Allows a drawer front to be fixed to the front of the pull-out frame
> Conceals the frame and dividers and makes it possible to add a
lock to jewelry drawers
> A unique design feature for limitless customization to the
appearance of the closet
> Simple to install and makes drawer face mounting easy
> Drawer front maximum height: 127 mm (5")
> W x H x D: 60 x 75 x 4 mm (2 3/8" x 2 15/16" x 1/8")
> Material: Steel

Finish Item No.
white 807.77.796
black 807.77.596
Note Cannot be used with the Engage Pant Organizer.

FC 4.82 www.hafele.com/us
4/22
