Consumables and Tools
Drilling Hardware
Jig
→ Quick-Set Drilling Jig for Handles → Euro Handle-It for Pulls and Handles
> For pulls on doors or drawer fronts
> Ideal for small to medium size shops
> With metric and inch scale
> Use a 4.5 mm or 3/16" drill
> Material: Polycarbonate with hardened steel bushings; Color: black
Description Item No.
Jig 001.35.001
001.35.020
Repair kit
Consumables and Tools and drawer fronts Item No. Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> For precise drilling and positioning of handles on doors, flaps
> Convertible side stop, can be used horizontally and vertically
> Drilling bushings: for drilling Ø4.3–4.6 mm (11/64"–3/16")
> Drill hole spacing: adjustable from 64–143 mm (2 1/2"–5 5/8")
> Distance from edge: adjustable from 26–103 mm
(1 1/16"–4 1/16")
> Material: Plastic with hardened drilling bushings
Color
12 red 001.31.233
