Consumables and Tools
Drilling Hardware
Jigs
→ Drilling Jig for Puck Light
Item No.
001.35.052
Supplied With
1 Jig
1 2 1/4" Forstner bit
1 2 1/8" Forstner bit
1 12" x 3/8" drill bit
→ Drill Bit for Puck Light → Forstner Bit Assembly, for Puck Light
> Superior Austrian quality
> High grade steel material with patented wave cutting edge
> Patented cutting edge drills 10x faster than standard bits
> Modified low-profile brad point tip for flat bottom hole
> With stop > Material: HSS Steel
> High grade steel material for increased drill life
> Allows for deeper wire holes Diameter Item No.
> Ø X L: 10 x 457 mm (3/8" x 18")
> Material: M2 HSS Steel 54 (2 1/8") 001.35.054
57 (2 1/4") 001.35.055
Supplied With
Item No. Adjustable depth stop
001.35.053 Collar
Supplied With Hex key
Hex key
→ HSS Twist Drill Bit Set, 3 piece → Häfele Drilling Jig
Consumables and Tools > For drilling deep holes in all types of wood, MDF and acrylic Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> With centering tip
> Lengths: Ø8–460 mm (5/16"–18 1/8")
> Precision drill holes in furniture side panels for leads and
Ø10–460 mm (3/8"–18 1/8")
switches for Loox lights
Ø12–250 mm (1/2"–9 13/16")
> Drill holes for soft closing mechanism for doors, dowels, shelf
> Material: HSS Steel
supports or cruciform mounting plates
> Compact design for already assembled furniture
Item No. > For table top thickness: 16, 19 and 25 mm (5/8", 3/4", 1")
12 001.20.354 > 5 mm (3/16") sleeves for drill holes for mounting plates
> Length: 75 mm (3")
Supplied With > Drilling sleeves: 8, 10 and 12 mm (5/16", 3/8", 1/2")
1 Bit of each size
Item No.
001.25.080
