Consumables and Tools
Drilling Hardware
Jigs
→ Euro Bit Self-Centering Tool
> Engineered to use different sizes of carbide boring bits
> 5 mm bit for shelf pins and attaching hardware with 32 mm
attachment screws
> 28 mm (7/64") adapter for #6 wood screws for hardware attachment
> Requires a boring bit with a 10 mm (40 mm) long shank or an
adapter for a 28 mm (7/64") twist drill bit
→ Drill Guide
> Material: Steel
Item No.
001.28.600
→ Euro Drill Bits, RH → Adapter
> Size: 5 mm > For 28 mm (7/64") drill bit
> Material: Carbide > Material: Aluminum
Item No. Item No.
001.24.700 001.28.602
Note
Drill is not included.
→ 32 mm Adjustable Line Boring Jig
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Made of high impact plastic for long life
> Aluminum bushing inserts for sturdy and straight drilling
> Drill guide fits exactly in insert without allowing drill bit to touch jig
> Provides a self-centering bore
> Improved design prevents clogging by wood chips
> Bits are interchangeable, only one guide necessary
> Material: Plastic/Aluminum
Item No.
001.27.007
Consumables and Tools
Note
Order Euro Bit self-centering tool separately.
