Consumables and Tools
Adhesives

Titebond ®

→ Original Wood Glue → Premium Wood Glue

> Fast set shortens clamp time > Designed for exterior use
> Excellent heat and solvent-resistance > Excellent heat and solvent-resistance
> Excellent sandability > Water clean-up
> Water clean-up > Ideal for radio frequency (R-F) and hot press gluing systems
> Bonds wood, hardwood, high pressure laminates and particleboard > FDA approved for indirect food contact (i.e. cutting boards)
APPLICATION GUIDELINES APPLICATION GUIDELINES
Application temperature: Above 50˚F. Application temperature: Above 55˚F.
Assembly time after glue application: 5 minutes (70˚F/50% RH) Assembly time after glue application: 5 minutes (70˚F/50% RH)
Minimum required spread: 7 mils (typical) Minimum required spread: 7 mils (typical)
Required clamping pressure: Enough to bring joints tightly Required clamping pressure: Enough to bring joints tightly
together (generally, 30-80 psi for HPL, 100-150 psi for softwoods, together (generally, 30-80 psi for HPL, 100-150 psi for softwoods,
125-175 psi for medium woods and 175-250 psi for hardwoods). 125-175 psi for medium woods and 175-250 psi for hardwoods).
Methods of application: Easily spread with a roller spreader or brush, Methods of application: Easily spread with a roller spreader or brush,
or may be transferred to plastic bottles for finer gluing applications. or may be transferred to plastic bottles for finer gluing applications.
Cleanup: Damp cloth while glue is wet. Scrape off dried excess. Cleanup: Damp cloth while glue is wet. Scrape off dried excess.
LIMITATIONS LIMITATIONS
Not intended for exterior use or where moisture is likely. For exterior Passes ANSI/HPVA Type II water-resistance tests. Do not use for
applications use Titebond II Premium Wood Glue. Freezing may joints below the waterline or continuous submersion. Freezing may
not affect the function of the product, but may cause it to thicken. not affect the function of the product but may cause it to thicken.
Agitation should restore product to original form. Agitation should restore product to original form. Because of variances
KEEP FROM FREEZING. in the surfaces of treated lumber, it is a good idea to test for adhesion.
KEEP FROM FREEZING.
BOND STRENGTH ASTM D-905 (On Hard Maple) BOND STRENGTH ASTM D-905 (On Hard Maple)
Temperature Strength psi % wood failure Temperature Strength psi % wood failure
Room Temperature 3,600 77 Room Temperature 3,750 72
150˚F Overnight 1,600 10 150˚F Overnight 1,750 6

Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

Size Item No. Size Item No.
1 gallon 003.15.001 1 gallon 003.15.011
2.15 gallons 003.15.004 2.15 gallons 003.15.016
5 gallons 003.15.002 5 gallons 003.15.012
Note Consumables and Tools
Chalk temperature indicates the lowest approximate temperature at which
the glue, air or materials to be bonded may be to assure a good bond.

→ Empty Glue Bottle and Cap with Control Tip

Description Item No.
16 oz. bottle 003.48.000
Cap with control tip 003.48.090
12

www.hafele.com/us FC 12.49
