Consumables and Tools
Screws

Varianta Screws

→ Varianta Euro Screw → Varianta Euro Screw
Length Length
VARIANTA VARIANTA
5 5
Ø7 Ø7.8
1.2 1.9 2.2

> With #2 Phillips drive > With #2 Phillips drive
> With special countersunk head > With special countersunk head
> For drawer slides > For hinge mounting plates, Tab, Tab-V, and Keku connectors
> For 5 mm system holes > For 5 mm system holes
> Material: Steel; Finish: nickel-plated > Material: Steel; Finish: nickel-plated

Length Item No. Packing Item No. Bulk Length Item No. Packing Item No. Bulk
10.5 (13/32") 013.50.718 500 pcs. 012.50.718 5,000 pcs. 10.5 (13/32") 013.51.715 500 pcs. 012.51.715 5,000 pcs.
13.5 (17/32") 013.50.727 500 pcs. 012.50.727 5,000 pcs. 13.5 (17/32") 013.51.724 500 pcs. 012.51.724 5,000 pcs.
16 (5/8") 013.50.736 500 pcs. 012.50.736 5,000 pcs. 16 (5/8") 013.51.733 500 pcs. 012.51.733 5,000 pcs.

> With #2 Pozi drive
> Material: Steel; Finish: nickel-plated

Length Item No. Bulk
15 (9/16") 012.14.727 5,000 pcs.

→ Varianta Euro Screw → Varianta Euro Screw

1.2 Length Length
VARIANTA VARIANTA
5 3
Ø9 Ø7.8
2.5 1.5
2.5
> With #2 Pozi drive > With #2 Pozi drive
> With special cylinder head > For 3 mm system holes
> For Rasant-Tab connectors, universal and back panel brackets > Material: Steel; Finish: nickel-plated
> For 5 mm system holes
> Material: Steel; Finish: zinc-plated
Length Item No. Packing Item No. Bulk
10.5 (13/32") 013.15.617 1000 pcs. – 012.15.626 – 5,000
Consumables and Tools 16 (5/8") 013.20.949 500 pcs. 012.20.949 2,500 pcs. → Round Washer Head Screws Ø13 1.5 Length Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Item No.
Bulk
Packing
Item No.
Length
500 pcs.
13.5 (17/32")
013.15.626
012.20.912
500 pcs.
013.20.912
11 (7/16")
5,000 pcs.
2,500 pcs.
012.20.930
013.20.930
15 (9/16")
500 pcs.
> Material: Steel; Finish: nickel-plated
Item No.
Bulk
Item No.
Length
Packing
013.20.716
11 (7/16")
012.20.716
500 pcs.
5,000 pcs.
500 pcs.
2,500 pcs.
16 (5/8")
013.20.743
012.20.743
1.5
> For 5 mm system holes with #2 Pozi drive
> For attachment of hardware in system holes, 2.2
universal brackets, accessories, etc.
> Material: Steel; Finish: zinc-plated
12
Length Item No. Packing
15 (9/16") 013.10.149 1000 pcs.
28 (1 1/8") 013.10.283 500 pcs.
FC 12.16 www.hafele.com/us
