Consumables and Tools
Screws

Wall Anchors

→ Self-Drilling Drywall Anchors

> Installs quickly and easily with Phillips or Square drive screwdriver
> Self-driving, pre-drills own small precise hole in gypsum wallboard
> Deep thread design provides strong engagement in 10, 13 and
16 mm (3/8", 1/2", 5/8") wallboard
> Removable, can be easily backed out
> Accepts #8 screw size
> Weight capacity: 50 lbs. shear strength
> Nylon version is non-conductive and corrosion resistant
> Material: Steel or Nylon

Finish Item No. Packing Item No. Bulk
Steel/zinc 051.18.027 100 pcs. 051.18.028 2,500 pcs.
Nylon/white 051.18.036 100 pcs. – –

→ SnapSkru Self-Drilling Drywall Anchors
®
> Unique “Snap Lock” feature provides the positive behind-the-wall
locking and holding power of a toggle bolt
> Creates only a 6 mm (1/4") hole
> Drywall thickness: min. 10 mm (3/8"); max. 16 mm (5/8")
> Material: Injection Molded Nylon

→ SPM Mini

> Weight capacity: 95 lbs. in 16 mm (5/8") drywall
Ø6 > Screw Ø: #6 (preferred), #7 and #8
(1/4") > Screw length: min. 25 mm (1") plus item thickness
SPM > Clearance behind wall for anchor: min. 16 mm (5/8") behind
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
32 (1 1/4") 13 mm (1/2") drywall; 13 mm (1/2") behind 16 mm (5/8") drywall
11 (7/16") > Color: white
Item No. Packing Item No. Bulk
051.18.040 100 pcs. 051.18.041 10,500 pcs.

→ SP Regular

> Weight capacity: 135 lbs. in 16 mm (5/8") drywall
Ø8 > Screw Ø: #8 (preferred), #6 and #10
(5/16") > Screw length: min. 32 mm (1 1/4") plus item thickness
SP > Clearance behind wall for anchor: min. 42 mm (1 5/8") minus
32 (1 1/4") wall thickness
16 (5/8")
Color Item No.
white 051.18.051 Consumables and Tools
Supplied With
5,500 pcs.

12

www.hafele.com/us FC 12.19
1/23
