Locks and Catches
Cabinet Locks

Automatic Door Bolt

> Locks double panel doors without additional stop strips or
furniture bolts
> The door catch is mounted inside the cabinet
> The hook and wedge element are mounted to the inside of either
the right or left door
> The door with the hook element must be closed first
Wedge > Upon closing the second door, the wedge element automatically
Element
min. door width = 406 mm (16") blocks the door catch
3.5 10 (3/8") 9.5 (11/32") > The door with the wedge element must now be made lockable
(1/8") with a lock
Wedge
Element
36 29 min. door width = 406 mm (16")
(1 7/16") (1 1/8") 3.5 10 (3/8") 9.5 (11/32")
8 (5/16") 10 (3/8") 10 (3/8") 17 (1/8")
10 (11/16")
Hook 3
(3/8")
Element (1/8")
4.2
(5/32")
32.5
(1 5/16") Hook
Element
2
11.5 (1/16")
(7/16")
> Must be combined with either a cam or deadbolt lock
11.5 (7/16") > Functions best when chosen lock locks into the cabinet top
31.5 or bottom
(1 1/4") > Make sure that doors lock tight without too much ‘play’ and that
44 (1 3/4") tall doors do not offer too much flex
> Material: Zinc die-cast
50 (2")
Flat Head
#5
Finish Item No.
nickel-plated 245.58.754
Note
Minimum door width is 406 mm (16").
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Double Door Latch
26 (1") Latch Activator > No need to reach inside cabinet to release elbow catch
> Doors can be closed in any order
24 > Low profile latch mechanism reduces product footprint
23 (15/16") inside cabinet
(29/32") > Requires use of a single lock (sold separately)
16
31.5 (5/8") > Allows two or three point locking for standard or wardrobe style
44 (1 3/4") (1 1/4") double door cabinets when used with a lock
60 (2 11/32") > Eliminates the need for an elbow catch, or other devices,
Catch and allows hardware to be installed out of the way
13 Latch Note
(1/2") Side 28
View (1 1/32") For cabinets taller than 1219 mm (48") it is recommended to use both
28 (1 3/32") top and bottom mount latches. For locking a pair of doors with one 10
31.5 16 lock (not included).
(1 1/4") (5/8")

> Easy to install and use
> Exceeds pull force above 150 lbs. Locks
> Material: Plastic

Color Lock Placement Item No.
black RH top mounted, LH bottom mounted 245.58.300
black LH top mounted, RH bottom mounted 245.58.301
white RH top mounted, LH bottom mounted 245.58.700
white LH top mounted, RH bottom mounted 245.58.701
Supplied With
Latch
Activator
Catch
Flat head screws pages 12.7–12.8, 12.10, 12.13 Mounting instruction
