Kitchen Organization
Cabinet Solutions

Dispensa BPO
3
> With soft close
> For overlay and inset doors
> Height adjustable frame mounts behind full door
> Trays are height adjustable
Kitchen Organization
> Top/bottom mounting with full extension frames provide full access
> Weight capacity: 27 kg (60 lbs.)

→ Frame

> 5 tray positions
> W × D: 95 × 543 mm (3 3/4" × 22 1/2")
> Installed height (A): 670–812 mm (26 3/8"–32")
> Material: Steel, powder-coated

Finish Item No.
champagne 546.62.826
silver 546.62.926
Supplied With Slides, Front brackets
Note Order wide bottom door bracket separately.
→ Short Frame

> For use in under drawer and reduced height applications
> 4 tray positions
> W × D: 95 × 543 mm (3 3/4" × 22 1/2")
543 (22 1/2")
> Installed height (A): 508–711 mm (20"–28")
> Material: Steel, powder-coated
Finish Item No.
A A
champagne 546.62.835
silver 546.62.935
Supplied With Slides, Front brackets Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Framed Frameless Note Order wide bottom door bracket separately.

→ Wide Bottom Door Bracket, optional

> W x H: 140 x 36 mm (5 1/2" x 1 7/16")
35 > Material: Steel
(1 3/8") M6 6
76.5 (1/4")
(3")
26.5 Finish Item No.
(1 1/16") champagne 545.09.890
silver 545.09.990
Supplied With
36
(1 7/16") Slides, Front brackets
Note
140 (5 1/2") Used to replace standard bottom bracket only. Order 1 pc. per unit.
FC 3.76 www.hafele.com/us
