Office Organization
Hanging File System

> Simple, flexible solution for mounting into any file drawer
> No cutting or grooving required to install
> Flush mount or top mount to drawer side, front, or back
> Accepts 3 mm (1/8") file bar

→ Bracket → Rail

11 2.5 m
(7/16") (98 1/2")
Pan Head
#6 8.5
22 (5/16")
26 (7/8")
5 (1")
side
thickness
10
(3/8")
> Snaps onto drawer sides, requiring no glue or staples
Office Organization Finish Item No. > Material: Plastic Side thickness Item No.
> Add clips and cross rails to accommodate different sized drawers
> Flush mount; screw mounted
and file sizes
> Material: Steel, 16 gauge
> Length: 2.5 m (98 1/2")
424.31.900
zinc-plated
Color
424.31.300
black oxide
12 (1/2")
422.72.381
black
422.73.790
white
12 (1/2")
→ Bracket
422.73.792
16 (5/8")
white
16 black 16 (5/8") 422.72.392
(5/8")
→ Rail Clip
18
(3/4")
19 25
23 (3/4") (1")
(7/8")
18
(3/4")
> Top mount; screw mounted
> Material: Steel, 16 gauge > Hangs over file rail (above), allowing files to be hung at
90º angle to rails
> Material: Plastic
Finish Item No.
zinc-plated 424.31.910
black oxide 424.31.310 Color Item No.
black 422.73.300
Supplied With 10 pcs.
→ Cross Rail
→ Aluminum Rail
11 2.5 m 4.5 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(7/16") (98 1/2") (3/16")
2.5 m 11.5
3 (98 1/2") (7/16")
(1/8") 24.2
(15/16")
> Fits in brackets above 3
> Easily cut to length for your application (1/18")
> Material: Aluminum, unfinished 7.4
(5/16")
Item No. > Without holes; drill holes where needed
> Length: 2.5 m (98 1/2")
422.74.900 > Material: Aluminum, anodized
Finish Item No.
satin silver 422.71.902
Pan head screws pages 12.9-12.10
