Office Organization
Hanging File System

File Frame Kit

> Inside drawer height of 222 mm (8 3/4") is required
> Smooth surface allows files to glide with ease
> Rigid profile handles heavy loads
> Adjusts between filing configurations without tools
> Cross rails “snap” into fixed positions
> Cut-to-size side rails allow you to customize any drawer
> Two or more kits may be combined for use in wide lateral file drawers

5

→ Frame for Wood or Metal Drawers

> Letter width file drawer requirements: Office Organization
Flat Head Inside width greater than 305 mm (12");
#6
Inside depth less than 584 mm (23")
> Legal width file drawer requirements:
Inside width greater than 381 mm (15");
Inside depth less than 584 mm (23")
> Material: Profile: Steel; Ends: Plastic; Color: black
Width Item No.
Letter 422.74.310
Legal 422.74.320
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Supplied With 2 Fixed front rails, 2 cut-to-size side rails (25" long),
2 Attachment brackets, Divider
CTC CTC
310 (12 3/16") 386 (15 3/16")

238 238
(9 3/8") (9 3/8")
298 375
(11 3/4") (14 3/4")
Typical LETTER file dimensions Typical LEGAL file dimensions
→ Depending on your drawer size, the following file configurations may be possible

Side to Side Legal Side to Side Letter Side to Side Legal Side to Side Letter

Front to Back Legal Front to Back Letter Front to Back Legal Front to Back Letter

Flat head screws pages 12.7-12.8, 12.10, 12.13
