Home and Closet Organization
Wardrobe Fittings

Wardrobe Tubes

4

Welded tube

→ Oval Wardrobe Tube, welded

> Material: Steel Home and Closet Organization
(1 3/16") 1.0 1.5
30 30 (1 3/16") Material thickness Finish Length Item No.
1.0 chrome-plated 2500 (98 7/16") 801.13.201
15 15 1.5 chrome-plated 2500 (98 7/16") 801.09.239
(9/16") (9/16")
1.0 chrome-plated 2337 (92") 801.13.209
1.0 black 2337 (92") 801.13.309
Note
Supports ordered separately, see next page.
→ Oval Wardrobe Tube
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
> Length: 2438 mm (96")
1.3
> Material: Aluminum
30 (1 3/16") > Material thickness: 1.3 mm
15 Finish Item No.
(9/16") matt aluminum 801.13.391
matt nickel 801.13.691
black 801.13.381
Note
Supports ordered separately.

→ End Caps

> For oval tubes 801.13.201 and 801.13.209
> Caps are inserted by pushing into the end of the tube
> Material: Plastic

Finish Item No.
chrome-plated 802.05.295

Supports page 4.130

www.hafele.com/us FC 4.129
