Page 302 - Furniture Cabinetry Hardware-FloorKitchenResource.com
P. 302
Home and Closet Organization
Wardrobe Fittings
TAG Synergy Elite
> Easy to use, pull out and rotate for full viewing
> Mounts with four screws
> Slides have detent in and out to hold mirror in place
> Ideal for spaces where installation is required on the outside of a
panel and rotated inwards
> Mirror extends 151 mm (6") from the front edge of the closet
4 allowing up to 345° rotation
> Provides great viewing angles from almost anywhere in a closet
> 889 mm (35") height mirrors allow for installation above jewelry
drawers, inside upper hanging sections or anywhere you’re a little
short on space.
> Length: 333 mm (13 1/8")
Home and Closet Organization → Full Rotation Mirror (14") (14")
> Width: 889 mm (35") mirror: 33 mm (1 5/16")
1203 mm (47 3/8") mirror: 38 mm (1 1/2")
> Material: Aluminum
356
356
333
(13 1/8")
333
(13 1/8")
889
(35") 470
(18 1/2") 1203
470
1473 - 1626 (47 3/8") (18 1/2")
(58" - 64")
33
(1 5/16")
1321 - 1473
(52" - 58") 38
25 (1 1/2")
(1")
Ground
30
(1 3/16")
Ground
Finish Height Item No.
matt aluminum 889 (35") 805.73.021
black 889 (35") 805.73.421 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
matt gold 889 (35") 805.73.921
matt nickel 889 (35") 805.73.621
slate 889 (35") 805.73.321
matt aluminum 1203 (47 3/8") 805.73.022
black 1203 (47 3/8") 805.73.422
matt gold 1203 (47 3/8") 805.73.922
matt nickel 1203 (47 3/8") 805.73.622
slate 1203 (47 3/8") 805.73.322
FC 4.104 www.hafele.com/us
4/22
