Home and Closet Organization
Wall Mount Organizer

TAG Symphony

> The Quartet is ideal for low-profile, quickly-accessible storage of
hanging objects like umbrellas, coats, belts, and backpacks
> Narrower widths mount above vanities or on the sides of cabinets
to store jewelry and accessories
> Broader widths deliver endless wall-mounted storage options
wherever they are needed in the home
> Weight capacity: max. 22.7 kg (50 lbs.) per horizontal bar and 4
max. 90 kg (200 lbs.) total for a system, evenly distributed

→ Quartet

> Height: 483 mm (19")
> Material: Aluminum/Faux Leather Home and Closet Organization

Width
Metal fi nish Leather color 342 (13 1/2") 584 (23") 889 (35") 1194 (47")
oyster 807.73.002 807.73.001 807.73.000 807.73.602
matt
nickel winter 807.73.601 807.73.600 807.73.802 807.73.801
pewter 807.73.800 807.73.302 807.73.301 807.73.300
oyster 807.73.012 807.73.011 807.73.010 807.73.612
matt
aluminum winter 807.73.611 807.73.610 807.73.812 807.73.811
pewter 807.73.810 807.73.312 807.73.311 807.73.310
oyster 807.73.022 807.73.021 807.73.020 807.73.622
slate
gray winter 807.73.621 807.73.620 807.73.322 807.73.321
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
pewter 807.73.320 807.73.822 807.73.821 807.73.820
oyster 807.73.032 807.73.031 807.73.030 807.73.632
matt
gold winter 807.73.631 807.73.630 807.73.832 807.73.831
pewter 807.73.830 807.73.332 807.73.331 807.73.330
oyster 807.71.310 807.71.311 807.71.312 807.71.313
black winter 807.71.810 807.71.811 807.71.812 807.71.813
pewter 807.71.610 807.71.611 807.71.612 807.71.613
Recommended # of Hooks 4 8 12 16
Supplied With
4 horizontal bars, 2 vertical mounts, Mounting hardware
Note
Order hooks and accessories separately, see pages 4.77–4.77C.
Widths 70
342 584 889 1194 (2 3/4")
(13 1/2") (23") (35") (47") Front of
Length (19") Wall Mount Use 3/16" toggle bolts
Symphony
483
with #10-24 screws (included)
Wall Wall when assembling to drywall
Use #8 wood screws
when assembling to wood

www.hafele.com/us FC 4.75
11/22
