P. 146
Kitchen Organization
Shelving/Railing Systems
Kitchen Rail System
Backsplash Railing System
3
> Ø16 mm (5/8") seamless tubing
> End caps plug into rails
Kitchen Organization
Installed along the Installed on top Ø16.2 Wall mounted
front of the countertop of the countertop (5/8") 46
26 (1 7/8")
(1 1/16")
→ Tubular Rail → Railing Posts M4
internal
thread Ø8 (5/16")
Ø14
Ø16.2 (9/16")
(5/8") 46 50
26 (1 7/8") (2")
(1 1/16") Ø8 (5/16")
M4
internal 15
thread Ø8 (5/16") (9/16")
Ø14
(9/16")
50
(2")
> Length: 1500 mm (59 1/16") > Press-fits over fastening screw Ø8 (5/16")
> Material: Steel > Material: Zinc 15
(9/16")
Finish Item No. Finish Item No.
chrome polished 522.00.236 chrome polished 522.02.212
stainless steel 522.40.015 stainless steel 522.42.000
Supplied With
→ Elbow Section, 90° M4 Set screw and hex key
→ S-Hook for Railng
Ø16
(5/8")
Countertop
Edge
55
51 (2 3/16")
(2")
85 26 51
(3 3/8") (1") (2")
26 27
(1") (1 1/16")
Ø13 Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
(1/2")
> Material: Steel
85
(3 3/8")
Finish Item No.
> Material: Steel chrome polished 522.04.207
Finish Item No.
stainless steel 522.41.010
FC 3.126 www.hafele.com/us
