Consumables and Tools
Material Handling
Support Materials
→ Lateral Parts Cart
> A heavy duty, cut-lumber delivery system
> Carries un-cut panels or can be configured with as many as 12 bins
> Allows workers to sort parts for easy identification and accessibility
> The end divider can be installed parallel or perpendicular with the
cart for greater flexibility
> With the uprights removed, the cart can be used as a lumber cart
> Narrow width is perfect for congested aisles
> W × H × L: 559 x 1498 x 1524 mm (22" × 59" × 60")
> Weight capacity: 907 kg (2000 lbs.)
> Material: Steel; Color: red
Item No.
Parts Cart 007.91.180
Replacement Casters 661.27.360
→ Protective End Caps
> Protects parts from damage
> Non-marring vinyl material
> Material: Vinyl Item No.
Consumables and Tools Supplied with Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Color
black
007.91.189
10 pcs.
12
FC 12.106 www.hafele.com/us
11/21
