Consumables and Tools
Adhesives

Titebond ®

→ Duramaster Sealant
™
> The first elastomeric, water-based sealant with 100%
joint movement*
> *Clear offers 25% joint movement
> For interior and exterior applications
> UV resistant
> For windows and doors
> For vinyl, metal, glass, wood, PVC, concrete, aluminum
and all types of siding
> Spans up to 2” wide, stays flexible, crackproof, paintable
and VOC-compliant
> Certified to Federal Specification TT-S-00230C , ASTM C920,
CLASS 100/50 (white and colors), ASTM C920, Class 25/25
(clear), ASTM C834, Type OP, Grade -18ºC, LEED v4.1 (white
and colors), AAMA 803.3-16 Type I (white and colors),
AAMA 808.3-16 Type I (white and colors)
APPLICATION GUIDELINES
Application Temperature: Above 40°F and below 120°F
Service Temperature Range: 0°F–160°F
Color Item No. Method of Application: Cartridge/caulking gun
white 003.51.005 Coverage (maximum): Approximate length of bead according
to bead diameter:
almond 003.51.006 Container bead 1/8" bead 1/4" bead 3/8" bead 1/2"bead
*clear 003.51.007 10.1 oz. Cartridge 123 ft. 31 ft. 14 ft. 8 ft.

black 003.51.020 Working time: Approx. 15 minutes for a 1/4" bead.
medium bronze 003.51.021 Working surfaces: Surfaces should be cleaned down to the
gray 003.51.022 original substrate, dry and free from excessive oil, grease, water,
clay 003.51.023 dirt or any material that may deter adhesion.
Painting: 2-4 hours with a high-performance water-based
ironstone 003.51.024 (latex) paint
redwood 003.51.025 Cleanup: Clean excess material with a damp cloth. Clean hands
woodtone 003.51.026 and tools with soapy water. Scrape dried excess.
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
dark brown 003.51.027 LIMITATIONS
tan 003.51.028 Do not apply if rain is expected within 24 hours. Air, sealant and
dark bronze 003.51.029 surface temperature should be above 40°F and rising. Protect from
rain for 24–48 hours after application.
Dry time may be extended in humid or cold conditions. Painting may
occur within 2-4 hours after application with a high-quality
water-based (latex-based) paint. For other paint types, a
compatibility test is recommended. To ensure neat sealant lines,
mask areas adjacent to joints. Always apply sealant in a bead form.
Once sealant is dry to the touch and does not transfer, remove
masking tape. If joint depth exceeds 1/2", use backing material.
NOTE: Highly recommend using backer rod/backing
Consumables and Tools
material for all joints. Sealant may appear to have a different tint/
color when initially extruded until it is fully dried/cured. Not designed
for continuous submersion or use below the waterline. Store unused
product in dry location at or below 70˚F (21˚C). Not for use with nail
holes or butt joints.

12

www.hafele.com/us FC 12.60A
4/22
