Connectors and Shelf Supports
Cabinet Shelf Supports

Supports

→ Ø3 mm → Ø5 mm

10.3 0.5 7 > Material: Plastic
11 1
4 Ø5
15.3 Color Item No.
Ø3 12 white 282.36.704
7.1
→ Ø5 mm
> With steel pin
> Weight capacity: 36 kg (80 lbs.)
> Material: Plastic, transparent; Pin: Steel, galvanized 2 7.5

Item No. Ø5 24
282.12.403 10
5
→ Ø5 mm 12 20

12.6 > With spring clip
0.5 10.6 > Material: Plastic
4 Ø5
14.5
Color Item No.
7.4 white 282.33.703
beige 282.33.409
> With steel pin
> Material: Plastic; Pin: Steel, galvanized
→ Ø5 mm

Color Item No. 7.5
white 282.12.705 1 6 > Provides invisible mounting
for grooved shelf
brown 282.12.105 25 3 > Material: Plastic
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
transparent 282.12.405
Color Item No.
→ Ø5 mm
white 282.21.703
10
0.5 11 → Ø5 mm

Ø5 4 Connectors and Shelf Supports
15 1.5
12.5
1.5
8 Ø5 19
> With steel pin 10.5
> Material: Plastic; Pin: Steel, galvanized 8.5 14

Color Item No. > Angular with collar
beige 282.27.509 > Material: Plastic, transparent
black 282.27.303
Item No.
11
282.22.013
→ Ø5 mm

11.5 > Weight capacity: 75 kg (165 lbs.)
7 11
> Material: Plastic
Ø5
1.5 2 15
Color Item No.
white 283.63.715
beige 283.63.411

www.hafele.com/us FC 11.121
