Office Organization
Cable Management

Metal Grommets

> Metal grommets are an elegant upgrade from standard
plastic grommets
> With straight edge, they can be recessed into top for
flush applications

→ One-piece, round

12 > For press-fitting or gluing in Ø40 mm (1 9/16") holes
(1/2") > Two aperture openings to choose from
15 > Material: Zinc die-cast, plated or epoxy-coated
(9/16") Ø46
(1 13/16")
5 Finish 12 x 15 mm 20 x 25 mm
Ø40 (1/2" x 9/16") (13/16" x 1")
3 (1 9/16") chrome polished 429.94.212 429.94.221
(1/8")
15 (1/2") brass polished 429.94.810 429.94.829
12
(9/16")
Office Organization (1") (13/16") (1 13/16") brushed nickel 429.94.612 429.94.621
429.94.319
black epoxy
429.94.310
429.94.026
brushed bronze
429.94.034
20
429.94.421
429.94.412
matt nickel
25
Ø46
Ø40
3
15 (1/8") (1 9/16")
12
(9/16") (1/2")
→ One-piece, round
21 > For press-fitting or gluing in Ø63 mm (2 1/2") holes
(13/16")
> Opening: 21 x 29 mm (13/16" x 1 1/8")
> Material: Zinc die-cast, plated or epoxy-coated
29
(1 1/8") Ø76
(3")
Finish Item No.
Ø63 chrome polished 429.94.258
(2 1/2") brass polished 429.94.856
3
(1/8") antique copper 429.94.151
15 12
(9/16") (1/2") black epoxy 429.94.346
brushed bronze 429.94.061
brushed nickel 429.94.658
matt nickel 429.94.448
→ Two-piece, round Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.

21 > For press-fitting or gluing in Ø61 mm (2 3/8") holes
(13/16")
> Opening: 21 x 29 mm (13/16" x 1 1/8")
> Material: Zinc die-cast, plated or epoxy-coated
29
(1 1/8") Ø75
(3")
Finish Item No.
black epoxy 631.46.302
Ø61
(2 3/8") matt nickel 631.46.602
6
(1/4") polished brass 631.46.802
21 14
(7/8") (9/16")

FC 5.22 www.hafele.com/us
