Consumables and Tools
Drilling and Insertion Machines

Bits

→ Machine Boring Bit → Drill Bit Kit for Hinge Machines

Description Item No.
Adaptor 10 (3/8") F/2.4 (1/16") 001.06.849
Carbide LH Ø 2.4 x 57 (1/16" x 2 1/4") 001.06.851 > Material: Steel
Carbide RH Ø 3 x 57 (1/8" x 2 1/4") 001.06.855
Carbide LH Ø 3 x 57 (1/8" x 2 1/4") 001.06.856
Carbide RH 5 x 57 (3/16" x 2 1/4") 001.06.868 Item No.
Carbide LH 5 x 57 (3/16" x 2 1/4") 001.06.869 001.06.871
Carbide RH Ø 5 x 70 (3/16" x 2 3/4") 001.08.020 Supplied With
Carbide LH Ø 5 x 70 (3/16" x 2 3/4") 001.08.021 Carbide bit - 35 x 57 mm
2 Carbide LH bits - 8 x 57 mm
Carbide Tip RH V-Point 5 x 57 (3/16" x 2 1/4") 001.08.060
Carbide Tip LH V-Point 5 x 57 (3/16" x 2 1/4") 001.08.061 → Brad Point Drill Bit Set
Carbide LH 8 x 57 (5/16" x 2 1/4") 001.06.870
Carbide RH Ø 8 x 70 (5/16" x 2 3/4") 001.08.022 > Premium 8 piece
Carbide LH Ø 8 x 70 (5/16" x 2 3/4") 001.08.023 > Sizes: 3, 4, 5, 6, 7, 8, 9 and 10 mm
Carbide LH Ø 10 x 57 (3/8" x 2 1/4") 001.06.875 > Precision German-made
Carbide RH Ø 10 x 57 (3/8" x 2 1/4") 001.85.408 > Material: Chrome Vanadium
Carbide RH Ø 12 x 57 (1/2" x 2 1/4") 001.06.876
TS.W/Center Spur RH Ø 14 x 70 (9/16" x 2 3/4") 001.20.187 Item No.
Carbide RH Ø 15 x 57 (19/32" x 2 1/4") 001.08.000 001.20.279
Carbide Ø 16.5 x 57 (5/8" x 2 1/4") 001.24.194
Carbide RH Ø 18 x 57 (11/16" x 2 1/4") 001.06.365
Dimensional data not binding. Dimensions in mm, inches are approximate. We reserve the right to alter specifications without notice.
Carbide RH 19 x 57 (3/4" x 2 1/4") 001.08.014
Carbide RH Ø 20 x 70 (13/16" x 2 3/4") 001.08.001
Carbide RH Ø 20 x 57 (13/16" x 2 1/4") 001.08.002 → Twist Drill Bit Set
Carbide LH Ø 20 x 57 (13/16" x 2 1/4") 001.08.003
Carbide RH 20 x 57 (13/16" x 2 1/4") > 25 piece
Flush Rafix F/16 (5/8") 001.24.309 > Sizes: 1–13 mm
Carbide RH 20 x 57 (13/16" x 2 1/4") 001.24.327 > Material: High-speed Steel
Flush Rafix F/19 (3/4")
Carbide LH 20 x 57 (13/16" x 2 1/4") Item No.
Flush Rafix F/19 (3/4") 001.24.337 001.04.181
Carbide RH 20 x 70 (13/16" x 2 3/4") 001.24.340
Flush Rafix F/19 (3/4")
Carbide LH 20 x 70 (13/16" x 2 3/4")
Flush Rafix F/19 (3/4") 001.24.341
Carbide RH 20 x 47 (13/16" x 1 7/8") 001.24.342 → Multipurpose Carbide Tip Drill Bit Set Consumables and Tools
Flush Rafix F/19 (3/4")
Carbide RH Ø 26 x 57 (1" x 2 1/4") 001.08.004 > 118° with 4 sharpened edges
Carbide RH Ø 28 x 70 (1 1/8" x 2 3/4") 001.08.012 > Sizes: 4, 5, 6, 8 and 10 mm
Carbide RH Ø 30 x 57 (1 3/16" x 2 1/4") 001.04.190 > Easy drilling into hard wood, metal and tile
Carbide RH Ø 35 x 70 (1 3/8" x 2 3/4") 001.08.006 > Material: Carbide
Carbide RH Ø 35 x 57 (1 3/8" x 2 1/4") 001.08.013
Carbide RH Ø 40 x 57 (1 5/8" x 2 1/4") 001.06.865 Item No.
W/Center Spur RH Ø 55 x 57 (2 3/16" x 2 1/4") 001.07.513 001.74.000
W/Center Spur RH Ø 58 x 57 (2 5/16" x 2 1/4") 001.07.522 12
W/Center Spur RH 60 x 57 x 10 (2 3/8" x 2 1/4" x 3/8") 001.08.040
W/Center Spur RH 68 x 70 x 10 (2 11/16" x 2 3/4" x 3/8") 001.08.016
W/Center Spur RH 80 x 70 x 10 (3 1/8" x 2 3/4" x 3/8") 001.08.050

www.hafele.com/us FC 12.91
